Hydrauli Gullotine shearing machine QC11Y
Request a Quote
Out of Stock
Main features:
1. The second generation of hydraulicshear
2. Welded steel plate construction,stress relieved
3. Advanced integrated hydraulicsystem with excellent reliability
4. 3-point support on the rollingguide with for improved shearing quality
5. Rapid, accurate, and convenientadjustment of blade clearance with hand wheel
6. Rectangular blades with 4 cuttingedges for long cutting life
7. Adjustable rake angle to minimizeplate deformation
8. Cutting beam with inner-inclinedstructure provides easy fall down for plates and high accuracy
9. Shearing in section: Shadow-linecutting
10. Counter for the motorized backgauge
Nationwide
Delivery
Delivery
Pay via
M-Pesa
M-Pesa
100% Genuine
Products
Products
Genuine & Warranted
Sourced from trusted suppliers with manufacturer-backed warranty.
Fast Nationwide Delivery
Countrywide dispatch with reliable courier partners across Kenya.
Expert Support
Talk to our team on WhatsApp for specs, quotes and bulk orders.
Product Description
| Model | Mild | Cutting | Depth Of | Back Gauge | Rake Angle Adjustment | Strokes Per Minute | Main Motor | L×W×H(mm) | Weight(t) |
| Steel | Length | Throat(mm) | Range(mm) | ||||||
| (450MPA) | (mm) | ||||||||
| 4×2000 | 4 | 2000 | 80 | 350 | 0.5°～1°30′ | 14 | 5.5 | 2600×1350×1840 | 3.8 |
| 4×2500 | 4 | 2500 | 80 | 350 | 0.5°～1°30′ | 14 | 5.5 | 3125×1450×1765 | 4.5 |
| 6×2500 | 6 | 2500 | 80 | 600 | 0.5°～1°30′ | 14 | 7.5 | 3100×1725×1900 | 5.3 |
| 6×3200 | 6 | 3200 | 80 | 600 | 0.5°～1°30′ | 12 | 7.5 | 3935×1840×1995 | 6.5 |
| 6×4000 | 6 | 4000 | 80 | 600 | 0.5°～1°30′ | 10 | 7.5 | 4650×1840×2075 | 7.5 |
| 6×5000 | 6 | 5000 | 80 | 600 | 0.5°～1°30′ | 8 | 7.5 | 5650×1830×2250 | 10.5 |
| 6×6000 | 6 | 6000 | 80 | 600 | 0.5°～1°30′ | 8 | 7.5 | 6650×1980×2380 | 15.2 |
| 8×2500 | 8 | 2500 | 80 | 600 | 0.5°～1°30′ | 14 | 7.5 | 3135×1840×2075 | 6 |
| 8×3200 | 8 | 3200 | 80 | 600 | 0.5°～1°30′ | 12 | 7.5 | 3850×1750×1980 | 6.8 |
| 8×4000 | 8 | 4000 | 80 | 600 | 0.5°～1°30′ | 10 | 7.5 | 4650×1890×2075 | 8.5 |
| 8×5000 | 8 | 5000 | 80 | 600 | 0.5°～2° | 7 | 15 | 5805×2000×2500 | 12.5 |
| 8×6000 | 8 | 6000 | 100 | 600 | 0.5°～2° | 7 | 15 | 6805×2115×2715 | 19.8 |
| 10×2500 | 10 | 2500 | 120 | 600 | 0.5°～2°30′ | 10 | 15 | 3195×1915×2205 | 8.2 |
| 10×3200 | 10 | 3200 | 120 | 600 | 0.5°～2°30′ | 8 | 15 | 3895×1900×2235 | 9.15 |
| 10×4000 | 10 | 4000 | 120 | 600 | 0.5°～2°30′ | 6 | 15 | 4695×1970×2270 | 9.15 |
| 10×5000 | 10 | 5000 | 120 | 600 | 0.5°～2°30′ | 5 | 15 | 5905×2115×2715 | 16 |
| 10×6000 | 10 | 6000 | 120 | 600 | 0.5°～2°30′ | 5 | 15 | 6905×2115×2800 | 22 |
| 12×2500 | 12 | 2500 | 120 | 600 | 0.5°～2°30′ | 10 | 15 | 3195×1800×2210 | 8.7 |
| 12×3200 | 12 | 3200 | 120 | 600 | 0.5°～2°30′ | 8 | 15 | 3895×1800×2240 | 9.8 |
| 12×4000 | 12 | 4000 | 120 | 600 | 0.5°～2°30′ | 6 | 15 | 4710×1950×2485 | 13.4 |
| 12×5000 | 12 | 5000 | 120 | 600 | 0.5°～2°30′ | 5 | 18.5 | 5905×2115×2800 | 20 |
| 12×6000 | 12 | 6000 | 120 | 600 | 0.5°～2°30′ | 4 | 18.5 | 7000×2300×3100 | 29 |
| 16×2500 | 16 | 2500 | 120 | 600 | 0.5°～2°30′ | 8 | 15 | 3215×1970×2340 | 9 |
| 16×3200 | 16 | 3200 | 120 | 600 | 0.5°～2°30′ | 7 | 15 | 3915×1970×2455 | 11 |
| 16×4000 | 16 | 4000 | 120 | 600 | 0.5°～2°30′ | 6 | 15 | 4715×2010×2590 | 15 |
| 16×5000 | 16 | 5000 | 120 | 600 | 0.5°～3° | 5 | 22 | 6000×2300×3000 | 23 |
| 16×6000 | 16 | 6000 | 120 | 600 | 0.5°～3° | 4 | 37 | 7000×2300×3100 | 36 |
| 20×2500 | 20 | 2500 | 120 | 600 | 0.5°～3° | 6 | 22 | 3235×2020×2465 | 10.5 |
| 20×3200 | 20 | 3200 | 120 | 600 | 0.5°～3° | 5 | 30 | 4150×2065×2755 | 18 |
| 20×4000 | 20 | 4000 | 120 | 600 | 0.5°～3° | 4 | 30 | 4955×2125×2885 | 21 |
| 20×5000 | 20 | 5000 | 120 | 600 | 0.5°～3° | 4 | 37 | 6000×2300×3050 | 29 |
| 25×2500 | 25 | 2500 | 120 | 600 | 0.5°～3.5° | 5 | 30 | 3465×2130×2710 | 15.3 |
| 25×3200 | 25 | 3200 | 120 | 600 | 0.5°～3.5° | 5 | 30 | 4120×2200×3000 | 21 |
| 25×4000 | 25 | 4000 | 120 | 600 | 0.5°～3.5° | 3 | 30 | 4950×2200×3150 | 26 |
| 30×2500 | 30 | 2500 | 120 | 600 | 1°～3.5° | 4 | 30 | 3465×2170×2770 | 17 |
| 30×3200 | 30 | 2500 | 120 | 600 | 1°～3.5° | 3 | 37 | 4200×2300×3200 | 23 |
